Steren 201-747 4 x 8 Multi-Switch for Shaw Direct & DirecTV
SWST4180
We currently have 228 in stock.
Details
Phase III Compatible Satellite Shaw Direct and DirecTV HDTV 40-2300 MHz Sky Switcher Digital Satellite Multiswitch Distribution 8-Way Video Distribution Multiswitch
22 kHz tone-controlled dual control multi-receiver suitable for DSS, c-band, or ku-band dish installations. Connects up to 4 satellite LNB inputs to 8 satellite receivers.
Specifications:
Frequency Range: 950-2300 MHz
Noise Figure: 4.8 dB min
Cross Polar Isolation: 40 dB min
LNB to LNB Isolation: 35 dB min
Rec. to Rec. Isolation: 40 dB min
Control Voltage:
LNB A 13 V/0 kHz
LNB A 17 V/0 kHz
LNB B 13 V/22 kHz
LNB B 17 V/22 kHz
Power Supply Input: 24 Vdc
Receiver Power Input: 13/17 Vdc
22 kHz tone-controlled dual control multi-receiver suitable for DSS, c-band, or ku-band dish installations. Connects up to 4 satellite LNB inputs to 8 satellite receivers.
Specifications:
Frequency Range: 950-2300 MHz
Noise Figure: 4.8 dB min
Cross Polar Isolation: 40 dB min
LNB to LNB Isolation: 35 dB min
Rec. to Rec. Isolation: 40 dB min
Control Voltage:
LNB A 13 V/0 kHz
LNB A 17 V/0 kHz
LNB B 13 V/22 kHz
LNB B 17 V/22 kHz
Power Supply Input: 24 Vdc
Receiver Power Input: 13/17 Vdc
