Cable Concepts Low Voltage Cable, 18 AWG, 3 Conductor, FT4/CSA Approved, 1000 Ft, Brown

WICH0300BN

We currently have 73 in stock.

You need to be a Registered Dealer to order this product. Please Login to your account or click here to Register.

Details

Cable Concepts Low Voltage Cable (LVT), 18 AWG, 3 Conductor, 1000 Ft.

This cable can be used both indoor and outdoor, is (FT4) fire rated, but is NOT suitable for burial. This cable is ISO / UL / CUL / CSA approved.

Application: Used for power limited circuits such as thermostat, air conditioning and heating controls, heat pumps, bell and alarm systems, signal systems, intercom systems, door bells, remote control units where maximum voltage does not exceed 30 Volts.


 1) Description
18 Gauge, 3 Conductor solid bare copper, 0.010
Non plenum insulation, Overall 0.015 Jacket, UL & CSA
2) Physical Dimensions
Center Conductor: 1.02+0.01mm BC
Insulation: 1.53+0.02mm PVC
Thickness: 0.255mm
Color Code: Black & Red
Jacket: 3.96+0.05mm PVC
Thickness: 0.45mm
3) Mechanical Characteristics
Operating Temperature Range: 20 To +75
Installation Temperature Range: 0 To +60
 Voltage Rating: 30V
Capacitance: 26 pF/ft
DCR: 6.385 phms/1000ft @ 68°F
