Cable Concepts Cat5E Flooded / Outdoor, 4 Pr, 1000 Ft

WICH0005BK

We currently have 40 in stock.

You need to be a Registered Dealer to order this product. Please Login to your account or click here to Register.

Details

Cable Concepts Category 5e direct burial, with PVC jacket for outdoor use with gel filled flooded core designed for direct burial installations, UV resistant for above ground applications and flooded gel core for in ground use, 8 conductor, black outdoor jacket.

High performance data communication cable, suitable for 350MHz high speed data applications, gigabit Ethernet, fast Ethernet and 155Mbps TP-PMD/CDDI, excellent attenuation and crosstalk characteristics, exceeds EIA/TIA 568 B.2-1. It can be used both indoor and outdoor, is (FT4) fire rated, and is suitable for burial. This cable is CSA approved.

Construction Materials
Jacket Material PVC with flooded core
Conductor Material Solid Bare Copper
Insulation Material Polyethylene (PE)
Filler Gel Filled
Dimensions
Cable Length 305 m | 1000 ft.
Cable Weight 24 lbs.
Diameter Over Jacket 6.096 mm
Jacket Thickness 0.762 mm
Electrical Specifications
ANSI/TIA Category 5e
Characteristic Impedance 100 ohm
dc Resistance Unbalanced, maximum 5 %
dc Resistance, maximum 9.38 ohms / 100 m
Mutual Capacitance 4.6 nF / 100 m @ 1 kHz
Delay Skew, maximum 45 ns
Nominal Velocity of Propagation (NVP) 65 %
Operating Frequency, maximum 350 MHz

Transmission Standards

ANSI / TIA-568-C.2 | CENLEC EN 50288-3-1 | ISO/IEC 11801 Class D

Safety Voltage Rating

300 V

Dielectric Strength, maximum

1500 Vac | 2500 Vdc



Environmental Specifications

Environmental Space

UV resistant for outdoor and/or direct burial installations

Installation Temperature

0 °C to +60°C (+32 ° F to +140 °F)

Operating Temperature

-20 °C to +60°C (-4 ° F to +140 °F)



General Specifications

Cable Type

U/UTP (Unshielded)

Pairs, quantity

4

Cable Component Type

Horizontal wiring in LAN

Product Number

WICH0005

Jacket Colour

Black

Conductor Gauge, singles

24 AWG

Conductor Type, singles

Solid

Conductor, quantity

8

Packaging Type

Reel in a box

Rip cord

Yes

Sequential footage marking

Every two feet

Mechanical Specifications

Maximum recommended pulling tension

11 kg | 25 lb.


Certifications

FT4, CSA, CUL, UL
