Cable Concepts Speaker Wire 16AWG/4C, 65 Strand, FT4/CSA Approved, 500 Ft, White
SWCH16465WH
We currently have 49 in stock.
Details
| Cable Concepts Speaker Wire 16 gauge (65X0.16mm) 2 strand bare copper conductor; PVC insulation, ripcord PVC jacket. |
|
Application: Commercial audio, security systems, power limited control, sound & audio, Intercom/PA systems, broadcast and nurse call.
|
| 1) Physical Dimensions | |
| Center Conductor: | 65X0.16+0.01mm Strand Bare Copper |
| Insulation: | 2.0+0.02mm PVC |
| Insulation Thickness: | 0.254mm |
| Ripcord: | Yes |
| Jacket: | 5.60+0.03mm PVC |
| Jacket Thickness: | 0.38mm |
| 2) Mechanical Specification | |
| Operating Temperature Range: | -20 To +75 |
| Cable Weight: | 43.25 Lbs/Mft |
| Min. Bend Radius: | 2.2 in. |
| 3) Electrical Characteristics | |
| Operating Voltage: | 300 VRMS |
| Max. Conductor DCR: | 4.23 /Mft |
| Capacitance: | 33 pF/ft |
