Cable Concepts Plenum Speaker Wire 16AWG/2C, 65 Strand, CUL, FT6, UTP, CMP, 1000 Ft. White
SWCH616265WH
We currently have 14 in stock.
Details
| Cable Concepts Speaker Wire 16 gauge (65X0.16mm) 2 strand bare copper conductor; PVC insulation, ripcord PVC jacket. |
|
Application: Commercial audio, Security systems, Power limited control, Sound & audio, Intercom/PA systems, Broadcast, etc. |
| 1) Physical Dimensions | |
| Center Conductor: | 65X0.16+0.01mm Strand Bare Copper |
| Insulation: | 2.0+0.02mm PVC |
| Insulation Thickness: | 0.254mm |
| Ripcord: | Yes |
| Jacket: | 4.75+0.03mm PVC |
| Jacket Thickness: | 0.38mm |
| 2) Mechanical Specification | |
| Operating Temperature Range: | 20 Degrees to +75 Degrees |
| Cable Weight: | 23.9 Lbs/Mft |
| Min. Bend Radius: | 1.9 in. |
| 3) Electrical Characteristics | |
| Operating Voltage: | 300 VRMS |
| Max. Conductor DCR: | 4.23/Mft |
| Capacitance: | 33 pF/ft |
| 4) Approval: | |
| Approvals: |
CUL, FT6, UTP, CMP
|
