Cable Concepts Speaker Wire 14AWG/2C, 65 Strand, FT4/CSA Approved, 1000 Ft, White
1 SWCH14265WH
We currently have 28 in stock.
Details
| Cable Concepts Speaker Wire 14 gauge (65X0.33mm) 2 strand bare copper conductor; PVC insulation, ripcord PVC jacket. |
|
Application: Commercial audio, Security systems, Power limited control, Sound & audio, Intercom/PA systems, Broadcast and Nurse call.
|
| 1) Physical Dimensions | |
| Center Conductor: | 65X0.33+0.01mm Strand Bare Copper |
| Insulation: | 2.0+0.02mm PVC |
| Insulation Thickness: | 0.33mm |
| Ripcord: | Yes |
| Jacket: | 5.0+0.03mm PVC |
| Jacket Thickness: | 0.38mm |
| 2) Mechanical Specification | |
| Operating Temperature Range: | -20 to +75 |
| Cable Weight: | 37.50 Lbs/Mft |
| Min. Bend Radius: | 2.2 in. |
| 3) Electrical Characteristics | |
| Operating Voltage: | 300 VRMS |
| Max. Conductor DCR: | 2.62/Mft |
| Capacitance: | 32 pF/ft |
| 4) Approval: | |
| Approval: | NEC/(UL), CSA, FT4, CMG, CEC/C(UL) |
