Cable Concepts RG59 95% Br. 18AWG/2C Power Drain, FT4/CSA Approved, 500 Ft, Black
WICH5995BK
We currently have 1 in stock.
Details
| 1) Description |
|
20 gauge (0.81mm) solid bare copper center conductor, gas expanded
PE dielectric, shield of bare copper braid wire, jacket of PVC, with 18AWG/2C, Nominal coax O.D. 5.80mm.
|
| 2) Physical Dimensions | |
| Center Conductor: | 0.81+0.01mm Solid Bare Copper |
| Dielectric: | 3.66+0.05mm Foam PE |
| Braid Coverage: | 95%X16X6X0.16+0.005mm Bare Copper Wire |
| Jacket(coax): | 5.80+0.05mm PVC |
| 18AWG/2C: | 7X0.3.86+0.01mm Stranded Bare Copper |
| Insulation: | 1.63+0.03mm Solid PE |
| Jacket (2C): | 3.80+0.05mm PVC |
| Thickness(2C): | 0.85+0.05mm |
| 3) Mechanical Characteristics | |
| Operating Temperature Range: | -20C to +75C |
| Max. Recommended Pulling Tension: | 68 lbs |
| Min. Bend Radius (Install): | 2.5 in. |
| 4) Electrical Characteristics | |
| Sparker Test: | 3000 VAC |
| Impedance: | 75+3 Ohm |
| Capacitance: | 54+3pF/m |
| Velocity of Propagation: | 82% |
| SRL: | 20dB (10-300MHz) 100% Sweep Tested |
