    Cable Concepts Cat6, 23AWG, 4 Pr, FT4/CSA, 1000 Ft, Blue
WICH2106BL
Details
Cat 6 Technology
A Category 6 Ethernet cable is also referred to as a Cat6 network cable, Cat6 cable, Cat6 Ethernet cable, or Cat 6 data/LAN cable. A wired Cat 6 network is more reliable and secure than a wireless network for your internet connections. Category 6 cable is the cable standard for Gigabit Ethernet and other network protocols.
100% Solid Bare Copper Conductors
Pure bare copper produces a stronger signal along with better conductivity and flexibility when compared to copper clad aluminum (CCA). This cable supports up to 550 MHz and is suitable for 10Base-T, 100BASE-TX (Fast Ethernet), 1000BASE-T / 1000BASE-TX (Gigabit Ethernet) and 10GBASE-T (10-Gigabit Ethernet).
4 Twisted Pair
4 Pair, Unshielded Twisted Pairs (UTP), 23AWG, Solid Bare Copper Conductors for optimal signal strength.
Durable PVC Jacket
This Cat6 cable is covered in a high-quality pvc jacket for added cable durability, which makes it more durable, wear resistant, prevent entanglement and good look.
In-Wall Rated
CM Rated, CMG, CSA and FT4 for In-Wall applications. Universal connectivity to computers & network components, such as routers, switch boxes, network printers, network attached storage (NAS) devices, VoIP phones & PoE devices.
| 1) Description |
| 23 AWG solid bare copper conductors, Polyolefin insulation, twisted pairs |
| PVC jacket (red, orange, yellow, green, white, blue or gray) |
| Suitable Applications: Premise Horizontal Cable, Gigabit Ethernet |
| 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL |
| Component or Composite Video, AES/EBU, Digital Video, RS-422 |
| 2) Physical Dimensions | |
| Center Conductor: | 0.56+0.01mm BC |
| Insulation: | 0.953+0.02mm PE |
| Pair: | 4 |
| Overall Cabling Fillers: | Yes |
| Jacket: | 6.10+0.05mm PVC |
| Ripcord: | Yes |
| Spline | Yes |
| 3) Mechanical Characteristics |
 |
| Operating Temperature Range: | -20 to +75 |
| Installation Temperature Range: | 0 to +60 |
| Max. Recommended Pulling Tension: | 45 lbs |
| Min. Bend Radius (Install): | 0.25 in. |
| 4) Pair Identification: | |
| Pair 1 | Blue/White w/Co-Extruded Blue Stripe on White Single |
| Pair 2 | Orange/White w/Co-Extruded Orange Stripe on White Single |
| Pair 3 | Green/White w/Co-Extruded Green Stripe on White Single |
| Pair 4 | Brown/White w/Co-Extruded Brown Stripe on White Single |
| 5) Electrical Characteristics | |
| Capacitance: | 15.5 pF/ft |
| Velocity of Propagation: | 67% |
| Conductor DCR: | 9.380/100m |
| Impedance: | 1.0 100Mhz /100 + 15% |
| 100 200Mhz /100 + 22% | |
| 200 300Mhz /100 + 32% | |
| 6) Approvals: | CM, CMG, FT4, CSA |
